Emotion S

Design by Prof. Wulf Schneider & Partner

Emotion S: one of a kind, thanks to its oval silhouette and large, curving glass pane. Thanks to its shallow depth, large and optional rotating upper part, the stove offers flexible placement in any room. Emotion S can optionally be fitted with a heat accumulator for longer-lasting warmth. The base height can be customised to your requirements.

Emotion S

Emotion M

Emotion XXL

Technical data Downloads

Colour

Feature

Drawer

Caracteristic
details

Generous view of the fire through generously curved glass panel
Minimalist design: door handle and air control panel integrated into the silhouette
Upper part can be rotated by 60° in either direction (optional)

Wooden compartment or wooden compartment with drawer (optional)
Base height can be customised to your specifications
Heat accumulator available (optional)

Technical data

Nominal heat output	5,1 kW
Efficiency	≥ 75,0 %
Energy efficiency class
Room-air independent operation possible (optional)	yes
Catalytic converter (optional)	yes

We reserve the right to make technical and visual changes without announcement.

further technical details Compare models

Technical data

Emotion S 2.0

Nominal heat output	5,1 kW
Efficiency	≥ 75,0 %
Energy efficiency class
Room-air independent operation possible (optional)	yes
Catalytic converter (optional)	yes
External fresh air supply	yes
Flue connection piece	top / rear
Shared chimney flues admissible	yes
Average feed pressure	0,12 mbar
Waste gas mass flow rate	5,9 g/s
Waste gas connection piece temperature	312° C
Heat accumulator Thermostone (optional)	up to 75 kg of storage mass
Rotating right / left (optional)	60° in both directions (optional); further rotation angles upon request
Weight	139 kg
Fire box dimensions (h x w x d)	230 x 400 x 265 mm
Lining	steel
Body colour, steel	black (standard), grey, platinum

We reserve the right to make technical and visual changes without announcement.

Compare models


	Emotion S 2.0	Emotion M 2.0	Emotion XXL 2.0
Nominal heat output	5,1 kW	7 kW	7 kW
Efficiency	≥ 75,0 %	≥ 75,0 %	≥ 75,0 %
Energy efficiency class
Room-air independent operation possible (optional)	yes	yes	yes
Catalytic converter (optional)	yes	yes	yes
External fresh air supply	yes	yes	yes
Flue connection piece	top / rear	top / rear	top / rear
Shared chimney flues admissible	yes	yes	yes
Average feed pressure	0,12 mbar	0,12 mbar	0,12 mbar
Waste gas mass flow rate	5,9 g/s	7,0 g/s	7,0 g/s / 5,84 g/s (RLU)
Waste gas connection piece temperature	312° C	324° C	324° C
Heat accumulator Thermostone (optional)	up to 75 kg of storage mass	up to 90 kg of storage mass	135 kg (integrated as standard)
Rotating right / left (optional)	60° in both directions (optional); further rotation angles upon request	60° in both directions (optional); further rotation angles upon request	60° in both directions (optional); further rotation angles upon request
Weight	139 kg	154 kg	299 kg
Fire box dimensions (h x w x d)	230 x 400 x 265 mm	290 x 440 x 310 mm	290 x 440 x 310 mm
Lining	steel	steel	steel
Body colour, steel	black (standard), grey, platinum	black (standard), grey, platinum	black (standard), grey
